| Art. no. | Hardheid | Max. invering | Max. Last* | Stift |
| 063040/S | 40 | 4.0mm | 35kg | M12 |
| 063045/S | 45 | 4.0mm | 45kg | M12 |
| 063046/S | 45 | 4.0mm | 45kg | M16 |
| 063055/S | 55 | 4.0mm | 70kg | M12 |
| 063056/S | 55 | 4.0mm | 70kg | M16 |
| 063064/S | 65 | 3.7mm | 95kg | M12 |
| 063065/S | 65 | 3.7mm | 95kg | M16 |
| 063235/S | 35 | 5.1mm | 95kg | M16 |
| 063245/S | 45 | 5.0mm | 120kg | M16 |
| 063255/S | 55 | 5.0mm | 220kg | M16 |
| 063265/S | 65 | 5.0mm | 280kg | M16 |
| 063275/S | 75 | 5.0mm | 400kg | M16 |
| 063345/S | 45 | 5.4mm | 350kg | M20 |
| 063355/S | 55 | 5.4mm | 525kg | M20 |
| 063365/S | 65 | 5.0mm | 800kg | M20 |
* Maximale last per steun!
| Model | A | B | C | D | F | G | J | M | KG (GEWICHT) |
| 0630** | 120 | 40 | 60 | 100 | 14 | 11 | 14 | M12 | 0.40kg |
| 0632** | 183 | 50 | 75 | 140 | 30 | 13 | 20 | M16 | 0.86kg |
| 0633** | 228 | 68 | 112 | 182 | 34 | 18 | 26 | M20 | 2.25kg |
